IEC 60068-2-20:2021 PDF

Environmental testing - Part 2-20: Tests - Test Ta and Tb: Test methods for solderability and resistance to soldering heat of devices with leads

First page of standard IEC 60068-2-20:2021

Open preview (PDF)

Title (English):

IEC 60068-2-20:2021

Environmental testing - Part 2-20: Tests - Test Ta and Tb: Test methods for solderability and resistance to soldering heat of devices with leads

Document status:: Active
Format:: Electronic (PDF)
Number of pages:: 65
Publication date:: March 30, 2021
Edition:: IEC IS 60068 edition 6 version 1
ICS:: 19.040

Delivery type:

Full version35 €Read online 24h10 €Read online 72h15 €

Document language:

enru

Delivery time:Immediate download

Price:35 €

Description (English):

IEC 60068-2-20:2021 outlines Tests Ta and Tb, applicable to devices with leads and leads themselves. Soldering tests for surface mounting devices (SMD) are described in IEC 60068-2-58. This document provides procedures for determining the solderability and resistance to soldering heat of devices in applications using solder alloys, which are eutectic or near eutectic tin lead (Pb), or lead-free alloys. The procedures in this document include the solder bath method and soldering iron method. The objective of this document is to ensure that component lead or termination solderability meets the applicable solder joint requirements of IEC 61191-3 and IEC 61191-4. In addition, test methods are provided to ensure that the component body can be resistant to the heat load to which it is exposed during soldering. This edition includes the following significant technical changes with respect to the previous edition: - update of and clarification of pre-conditioning (former "aging") and its relation to natural aging.

Technical details

Technical committee: TC 91 - Electronics assembly technology
SKU: IEC 60068-2-20:2021

Abstract

Overview

IEC 60068-2-20:2021 is an international environmental test standard that defines Test Ta and Test Tb procedures for assessing the solderability and resistance to soldering heat of components with leads. It covers devices with through‑leads and lead terminations used with eutectic or near‑eutectic tin‑lead (Pb) or lead‑free solder alloys and specifies two principal test methods: the solder bath method and the soldering‑iron method. This edition clarifies pre‑conditioning (accelerated ageing) and how it relates to natural aging.

Key topics and requirements

Test scope
- Test Ta - verification of solderability of wire, tag terminations and leads.
- Test Tb - determination of component resistance to the thermal load of soldering processes.
Test methods
- Solder bath method: immersion-based wetting and heat exposure procedure.
- Soldering‑iron method: localized heating using a controlled iron tip.
Performance criteria
- Acceptance is based on achieving adequate wetting and avoiding unacceptable damage to the component body or lead terminations.
- Includes consideration of de‑wetting, contact angle/wetting behavior, and recovery after thermal exposure.
Pre‑conditioning (accelerated ageing)
- Procedures and clarification on how accelerated pre‑conditioning is used prior to solderability testing to simulate natural aging.
Supporting materials
- Guidance on flux types (colophony‑based compositions are referenced) and specimen preparation.
- Cross‑references to wetting balance methods (see IEC 60068‑2‑54 and IEC 60068‑2‑69) for quantitative wetting time/force data.

Applications and users

Who uses IEC 60068-2-20:
- Component manufacturers (through‑hole components, leaded devices)
- PCB assemblers and process engineers verifying solder processes
- Quality assurance and reliability teams validating component compatibility with tin‑lead and lead‑free soldering
- Test labs performing environmental and solderability qualification
Practical uses:
- Qualifying components to meet solder joint requirements in IEC 61191‑3 and IEC 61191‑4.
- Establishing process windows and acceptance criteria for wave soldering, hand soldering and other leaded‑component assembly operations.
- Assessing the impact of soldering heat on component integrity and termination wetting behavior.

Related standards

IEC 60068‑1 (general environmental testing guidance)
IEC 60068‑2‑58 (soldering tests for SMDs)
IEC 60068‑2‑54, IEC 60068‑2‑69 (wetting balance / quantitative wetting methods)
IEC 61191‑3, IEC 61191‑4 (requirements for soldered assemblies)
IEC 60194 (PCB terms and definitions)

Keywords: IEC 60068-2-20, solderability test, resistance to soldering heat, solder bath method, soldering iron method, leaded components, lead‑free solder, pre‑conditioning, PCB assembly, wetting.
