Overview
IEC 60068-2-47:2005 is an international standard published by the International Electrotechnical Commission (IEC) that provides detailed methods for mounting specimens for environmental vibration, impact, and similar dynamic tests. It covers mounting techniques for products, both packaged and unpackaged, as well as mounting requirements for equipment and other articles. These specimens are secured to test apparatuses to undergo dynamic tests under controlled conditions. This standard supports various tests in the IEC 60068-2 series, specifically:
- Impact (Test E)
- Vibration (Test F)
- Acceleration, steady-state (Test G)
A key update in this third edition is the inclusion of specific guidance on testing packaged products, addressing widely varying packaging conditions and ensuring reliable and consistent test results.
Key Topics
Mounting Techniques for Different Specimens
IEC 60068-2-47 emphasizes the importance of appropriate fixture and mounting for different specimen types:
- Components: Guidelines include mounting by leads, by body, or combinations to accurately represent operational conditions.
- Equipment and Articles: Covers fixation methods ensuring secure attachment without compromising test validity.
- Packaged Products: Addresses mounting methods when packaging is available or unavailable, including factors influencing transmissibility and shock absorption.
Dynamic Tests Requirements
- The standard ensures that specimens closely simulate real-world mounting and operational conditions during vibration, impact, or acceleration testing.
- It provides criteria to avoid introducing artifacts due to improper mounting, which could invalidate test outcomes.
- Recommendations help testers balance rigid fixation with the need to replicate real handling and transportation stresses.
Technical Annexes and Guidance
- Annex A offers general guidelines for mounting and test preparation.
- Annex B delivers specific advice about packaging materials, cushioning, and handling typical for packaged goods.
- Annex C explains dynamic responses using a single degree of freedom (SDOF) model to illustrate response to shocks, facilitating interpretation of test data.
Applications
IEC 60068-2-47 is critical for manufacturers, test labs, and quality control engineers engaged in:
- Environmental Stress Testing: Validating product robustness against vibration and shock during transportation, installation, or use in harsh environments.
- Packaging Evaluation: Ensuring packaging configurations adequately protect products through real-life shock and vibration exposures.
- Design Verification: Confirming mounting and fixation methods do not introduce vulnerabilities or damage during dynamic tests.
- Compliance and Certification: Supporting adherence to industry and regulatory standards that reference IEC 60068 series tests.
Utility spans across multiple sectors such as electronics, automotive components, aerospace equipment, consumer goods, and any field where products face dynamic environmental stresses.
Related Standards
IEC 60068-2-47 works in conjunction with other parts of the IEC 60068 series, which collectively provide a comprehensive framework for environmental testing:
For packaging-specific testing, guidance in IEC 60068-2-47 complements the requirements of ISO packaging standards and transport simulation protocols used globally.
Keywords: IEC 60068-2-47, environmental testing, vibration testing standard, impact test mounting, dynamic test methods, packaged products testing, product fixation, shock testing, IEC standards, specimen mounting, electronic component testing, packaging protection, vibration and shock simulation, single degree of freedom system, environmental stress testing.
Open preview (PDF)Environmental testing - Part 2-47: Test - Mounting of specimens for vibration, impact and similar dynamic tests
