IEC 60664-3:2016 PDF

Insulation coordination for equipment within low-voltage systems - Part 3: Use of coating, potting or moulding for protection against pollution

Open preview (PDF)

Title (English):

IEC 60664-3:2016

Insulation coordination for equipment within low-voltage systems - Part 3: Use of coating, potting or moulding for protection against pollution

Document status:: Active
Format:: Electronic (PDF)
Number of pages:: 77
Publication date:: November 4, 2016
Edition:: IEC IS 60664 edition 3 version 1
ICS:: 29.080.30

Delivery type:

Full version35 €Read online 24h10 €Read online 72h15 €

Document language:

enru

Delivery time:Immediate download

Price:35 €

Description (English):

IEC 60664-3:2016 applies to assemblies protected against pollution by the use of coating, potting or moulding, thus allowing a reduction of clearance and creepage distances as described in IEC 60664-1. This document describes the requirements and test procedures for two methods of protection: - type 1 protection improves the microenvironment of the parts under the protection; - type 2 protection is considered to be similar to solid insulation. This edition includes the following significant technical changes with respect to the previous edition: a) information added concerning interpolation; b) provided scratch test is only for type 2 protection; c) renumbered the scratch test to follow the visual examination test, since it makes more sense there; d) separated the tables under what is now called Annex A, to make them clearer.

Technical details

Technical committee: TC 109 - Insulation co-ordination for low-voltage equipment
SKU: IEC 60664-3:2016

Abstract

Overview

IEC 60664-3:2016 - "Insulation coordination for equipment within low-voltage systems - Part 3: Use of coating, potting or moulding for protection against pollution" specifies how coating, potting, or moulding can be used as permanent pollution protection to allow reductions in required clearance and creepage distances (as referenced in IEC 60664-1 / IEC 60664-5). The standard defines two protection types: type 1 (improves the micro-environment) and type 2 (treated as similar to solid insulation). It also establishes test methods, conditioning procedures and acceptance criteria for protected assemblies such as PCBs, substrates and multi-layer boards.

Key Topics

Scope and application: Applies to permanent protective systems on printed wiring boards, terminals and rigid assemblies; excludes assemblies after repair.
Protection types:
- Type 1: Improves microenvironment under the protective layer (less stringent than solid insulation).
- Type 2: Considered equivalent to solid insulation - enables greater reduction of creepage/clearance.
Design and dimensioning: Rules that permit reduced spacing only when appropriate protection and testing are applied; reference to minimum spacings (see standard Table 1 for type 2).
Testing requirements:
- Visual examination and scratch-resistance test (scratch test applies to type 2 protection only).
- Environmental conditioning: cold, dry-heat, rapid temperature change, damp heat with polarizing voltage, and electromigration conditioning.
- Electrical/mechanical tests after conditioning: adhesion, insulation resistance, AC withstand voltage, and partial discharge extinction voltage.
- Additional tests: resistance to soldering heat, flammability, solvent resistance, where applicable.
Specimens and test boards: Guidance for preparing coated/potted/moulded specimens and printed wiring board configurations for testing.
Notable updates in 2016 edition: interpolation guidance added; scratch test limited to type 2 and renumbered; Annex A tables separated for clarity.

Applications

Use by electrical designers, safety engineers, and PCB manufacturers to justify reduced creepage/clearance with permanent encapsulation.
Reference for component suppliers and assembly houses when specifying coatings, potting compounds or moulding processes for low-voltage equipment.
Essential for test laboratories and certification bodies performing environmental and electrical testing on protected assemblies.
Useful to standards committees defining product-specific insulation requirements.

Related Standards

IEC 60664-1 and IEC 60664-5 - overall insulation coordination and clearance/creepage rules.
IEC 60068 series - environmental test methods referenced for conditioning procedures.

This standard helps ensure safe, reliable pollution protection in low-voltage systems while allowing optimized PCB and assembly designs when coating, potting or moulding are applied.
