Overview
IEC 60850:2014 is an international standard published by the International Electrotechnical Commission (IEC) that defines the main characteristics of supply voltages for railway traction systems. It covers traction fixed installations, auxiliary devices powered by the contact line, and rolling stock used across various rail-bound transportation applications. This standard is essential for ensuring safety, interoperability, and reliable performance in railway electrical systems.
The standard applies to a broad range of railway applications, including:
- Conventional railways
- Guided mass transit such as tramways, light rail, elevated and underground railways, and trolleybus systems
- Rail-bound material transport systems like coal or iron-ore transportation
- Low-speed maglev trains and linear motor transport systems
IEC 60850:2014 is the fourth edition, updating and refining the previous 2007 edition by clarifying terms, completing requirements on voltages, modifying voltage tables, and revising annexes to reflect the latest technical developments.
Key Topics
-
Supply Voltages and Frequencies
Specifies nominal voltages, permissible limits, frequency values, and tolerances for traction systems. This includes detailed tables outlining voltage thresholds and durations to maintain system integrity.
-
Overvoltages and Voltage Variations
Defines different types of overvoltages such as long-term overvoltages, their causes, limits, and measurement techniques. Annex A includes voltage-time curves illustrating maximum allowable voltage values over time.
-
Testing and Measurement Methodology
Covers testing procedures to verify voltage and frequency compliance in rolling stock and fixed installations. It standardizes how voltage measurements on contact lines and frequency assessments should be conducted.
-
Electrical Safety and System Components
Relates to the coordination of insulation, protective earthing, and managing voltage distortions and interruptions to ensure operational safety and continuity of service.
-
Terminology and Definitions
Provides a harmonized vocabulary for terms related to electric traction systems, contributing to clarity and consistency across international rail systems.
Applications
IEC 60850:2014 is critical for professionals responsible for:
-
Railway Electrical System Design
Engineers specifying or upgrading traction power supplies rely on this standard to establish correct voltage parameters and confirm compatibility with rolling stock and infrastructure.
-
Rolling Stock Manufacturers
Ensures trains are capable of operating within the defined voltage ranges and withstand expected electrical conditions on the contact line.
-
Mass Transit Authorities
Transit agencies use IEC 60850 to maintain system reliability and define maintenance regimes based on voltage characteristics, minimizing service disruptions.
-
Material Transport Systems
Mining and bulk material transport via rail benefit from guidelines that ensure safe and effective electrification solutions.
-
Maglev and Linear Motor Transport Systems
Extends applicability to innovative low-speed magnetic levitation technologies, promoting unified standards for emerging transport modalities.
Related Standards
IEC 60850:2014 complements other essential IEC standards in railway electrical system design and safety, including:
- IEC 61133:2006 – Rolling stock testing protocols on completion of construction and prior to service entry.
- IEC 62128-1:2013 – Specifications on electrical safety, earthing, and return circuits of fixed installations.
- IEC 62497-2 – Guidelines on insulation coordination and overvoltage protection.
These standards collectively ensure harmonized electrical practices across rolling stock and fixed railway infrastructure, facilitating international interoperability and safety compliance.
