Overview
IEC 62680-1-2:2019 is an international standard that specifies the USB Power Delivery (USB PD) system for managing power delivery over Universal Serial Bus (USB) interfaces. It defines a comprehensive power delivery architecture that covers the full ecosystem including Hosts, Devices, Hubs, Chargers, and cable assemblies. The standard supports power delivery up to 100 watts, aiming for flexibility, compatibility, and versatility in USB-based power systems.
This fourth edition replaces the 2018 third edition and is also known as USB Power Delivery Specification Revision 3.0, Version 1.2. This revision integrates all previously issued Engineering Change Notices (ECNs), creating a consolidated and updated specification suitable for system OEMs, power supply manufacturers, and peripheral developers.
Key Topics
-
USB Power Delivery Architecture
The standard defines a scalable architecture that supports multi-directional power flow, allowing devices to both supply and receive power intelligently.
-
Protocol and Communication
IEC 62680-1-2 outlines the communication protocols between USB hosts, devices, and cables to negotiate power requirements and capabilities dynamically.
-
Power Supply Behavior
Specifies how power delivery is managed to ensure safe and efficient charging and power transfer, including voltage and current negotiation up to 100W.
-
Connectors and Cabling
Details requirements for USB connectors and cabling assemblies to support power delivery, maintaining backward compatibility with existing USB connectors and standards.
-
Compatibility and Market Flexibility
Designed to work seamlessly with existing USB infrastructure, the specification allows OEMs and developers to create differentiated products without sacrificing interoperability.
-
Standardization and Intellectual Property
Published under the collaboration of IEC and the USB Implementers Forum (USB-IF), the specification includes licensing terms and disclaimers relevant to implementation.
Applications
IEC 62680-1-2:2019 is essential for developing and deploying USB-enabled devices and systems that require advanced power delivery capabilities. Common applications include:
-
Mobile Device Charging
Smartphones, tablets, and laptops benefit from faster, smarter charging solutions enabled by USB PD.
-
Power Hubs and Docking Stations
USB hubs and docking stations use this standard to provide power distribution while maintaining data connectivity.
-
Peripheral Devices
External drives, monitors, and other USB peripherals can receive adequate power without separate adapters.
-
Chargers and Power Adapters
Chargers designed for USB PD can dynamically adjust power output according to connected device needs, optimizing power efficiency.
-
Consumer Electronics
Cameras, wearables, and other electronics utilize USB PD protocols to extend battery life and improve charging convenience.
Related Standards
-
IEC 62680 Series
The series covers USB interfaces for data and power, with specific parts addressing common components and functional extensions.
-
USB Type-C Specification
Often used alongside USB PD, Type-C defines physical connectors and cables, complementing the power delivery features.
-
IEEE and ISO Standards on Power Delivery
While IEC 62680-1-2 focuses on USB, related standards address electrical safety, interoperability, and broader power management protocols.
-
USB Implementers Forum (USB-IF) Compliance Programs
Compliance with USB-IF ensures device interoperability and adherence to USB PD and other USB standards.
Keywords: IEC 62680-1-2, USB Power Delivery, USB PD specification, USB power management, USB charging standard, USB data and power interface, universal serial bus, USB PD 3.0, USB connectors, USB cables, power delivery up to 100W, IEC standards USB, USB-IF compliance.
Open preview (PDF)Universal serial bus interfaces for data and power - Part 1-2: Common components - USB Power Delivery specification
