Overview
ISO 19233-1:2017 - "Implants for surgery - Orthopaedic joint prosthesis - Part 1: Procedure for producing parametric 3D bone models from CT data of the knee" specifies standardized procedures for generating accurate 3D bone models from CT data of the knee. The standard defines CT scanning conditions and reconstruction requirements to support applications such as preoperative planning, surgical navigation, robotic surgery, patient‑matched instruments and personalized total knee joint prostheses.
Key Topics
- Imaging conditions: Use a multi‑slice CT apparatus; scan in the supine position with the knee extended. Define a clear region of interest (full leg, femoral head–knee–ankle, or knee joint only).
- Field of view (FOV): Typically 200–250 mm; extend up to 320 mm for bilateral scans to maintain image resolution.
- Slice thickness & spacing: Minimize both values; if slice thickness > 2.0 mm or spacing > 1.5 mm, software validation is strongly recommended.
- Reconstruction kernel & CT settings: Select an appropriate reconstruction kernel. Set tube voltage within 80–140 kV and tube current to avoid noise; use Automatic Exposure Control (AEC) to reduce dose.
- Precautions: Mitigate metal artefacts (implants, external metals) and prevent patient movement during scanning. Use standing plain X‑rays to determine leg alignment and apply corrections to 3D models.
- Software & validation: Segmentation/generation software must meet Medical Device Software regulatory expectations, including design verification, documented risk analysis per ISO 14971, and validation of segmentation and 3D reconstruction algorithms.
- Segmentation methods: Supports pixel‑based and shape‑based techniques; operator involvement may be manual, semi‑automatic or automatic - automatic methods aim to reduce variability.
- Documentation & data formats: Requires traceable design history, functional verification, and validated data transfer from CT to output formats.
Applications
ISO 19233-1 is directly applicable to:
- Orthopaedic surgeons and radiologists preparing for complex knee procedures
- Medical device and implant manufacturers designing personalized knee prostheses and patient‑matched instruments
- Developers of surgical navigation, robotic surgery platforms and preoperative planning software
- Imaging departments and clinical engineers setting CT protocols for orthopaedic measurements
- Testing laboratories and regulatory teams validating segmentation and 3D reconstruction workflows
Related Standards
ISO 19233-1:2017 provides practical, actionable guidance to ensure reproducible, high‑quality parametric 3D bone models from knee CT data, improving the reliability of surgical planning, device design and image‑guided orthopaedic workflows.
Open preview (PDF)Implants for surgery — Orthopaedic joint prosthesis — Part 1: Procedure for producing parametric 3D bone models from CT data of the knee
