Overview
ISO 9093:2020 - "Small craft - Seacocks and through-hull fittings" sets safety, material and testing requirements for through-hull fittings, seacocks, hose connections and their installation on small craft up to 24 m hull length (per ISO 8666:2020). The standard excludes engine/heater exhaust and sail drive through‑hull fittings. It replaces earlier parts and adds installed strength, corrosion resistance and UV stabilisation tests (Annexes A–C).
Key topics and technical requirements
- Scope and definitions
- Applies to small craft with LH up to 24 m; defines terms such as through‑hull fitting, seacock, accessible and readily accessible.
- Material requirements
- Components located below the maximum load waterline must be corrosion‑resistant.
- Brass must be dezincification resistant (DZR) (tested per ISO 6509‑1/2).
- Material combinations must account for galvanic action and allow galvanic isolation when needed.
- Non‑metallic parts require UV stabilisation (Annex C).
- Strength and durability
- Seacocks, through‑hull and hose fittings must meet the installed strength test (Annex A) and corrosion testing (Annex B).
- Operability across a temperature range: operable from 0 °C to +60 °C; storage when dry from −40 °C to +60 °C.
- High/low temperature conditioning tests (24 h preconditioning) ensure operability after exposure.
- Design and construction
- Through‑hull fittings must provide a secure, watertight connection that cannot be dislodged by outside forces.
- Threaded fittings require permanent marking of thread size/type; minimum remaining thread length after installation must be at least 1.5× the table value.
- Flanges, counterplates and finishes must avoid sharp edges; flange diameter must be adequate relative to nuts/counterplates.
- Seacocks must allow operation under normal service conditions and permit a visual check of open/closed position.
- Installation and documentation
- Requires consideration of hull reinforcements, installation requirements, device installation information and inclusion of instructions in the owner’s manual.
Applications and who uses this standard
- Boatbuilders and naval architects specifying safe through‑hull systems for small craft
- Marine hardware manufacturers designing and testing seacocks, through‑hull fittings and hose fittings
- Marine surveyors, installers and maintenance personnel ensuring compliance and safe installation
- Yacht owners, operators and procurement teams selecting compliant marine fittings
- Classification societies and regulators assessing conformity and safety
