Industrial automation systems and integration — Product data representation and exchange — Part 1009: Application module: Shape appearance layers
Industrial automation systems and integration — Product data representation and exchange — Part 1009: Application module: Shape appearance layers
This site uses cookies and visit counters for operation and statistics. Privacy policy
ISO/TS 10303-1009:2010-07 specifies the application module for Shape appearance layers. The following are within the scope of ISO/TS 10303-1009:2010-07: assignment of layers to shape items; assignment of visual attributes to shape items; assignment of colour to surfaces; assignment of visual attributes to curves belonging to surfaces; items within the scope of application module Appearance assignment, ISO/TS 10303-1001; items within the scope of application module Fill area style, ISO/TS 10303-1672; items within the scope of application module General surface appearance, ISO/TS 10303-1007; items within the scope of application module Layer assignment, ISO/TS 10303-1008.
