Overview
SIST EN ISO 7053:2019, titled Fasteners - Hexagon washer head tapping screws (ISO 7053:2019), is an international standard that specifies the characteristics and requirements for hexagon washer head tapping screws made from steel and stainless steel. This standard covers thread sizes from ST2,2 to ST8 and denotes product grade A screws, ensuring consistency and compatibility in engineering and construction applications. The standard was developed collaboratively by ISO/TC 2 "Fasteners" and CEN/TC 185 “Fasteners,” providing harmonized requirements across international markets and replacing the previous edition (EN ISO 7053:2011).
Key Topics
-
Product Characteristics:
The standard details dimensions, mechanical properties, materials, and finishing options for hexagon washer head tapping screws, including:
- Thread sizes: ST2,2 to ST8 (with some non-preferred sizes in brackets)
- Materials: Steel and stainless steel (including A2-20H, A4-20H, and A5-20H stainless grades)
- Product grade: Grade A, signifying higher precision and strict tolerances
-
Geometry and Design:
- Hexagon washer head shape provides an integral washer, distributing load and increasing torque resistance.
- Multiple end types (rounded, flat, cone) accommodate diverse assembly requirements.
-
Mechanical and Functional Requirements:
- Mechanical properties for steel are specified in ISO 2702, while stainless steel properties are covered by ISO 3506-4.
- Threads conform to ISO 1478, and overall tolerances align with ISO 4759-1 for product grade A.
-
Surface Finish and Coating:
- Options for as-processed (clean and bright), electroplated (ISO 4042), or non-electrolytically applied zinc flake coatings (ISO 10683).
- Stainless steel screws are passivated for enhanced corrosion resistance (per ISO 16048).
-
Quality Assurance:
- Acceptance inspection process follows ISO 3269.
- General fastener requirements are outlined in ISO 8992.
Applications
SIST EN ISO 7053:2019 covers hexagon washer head tapping screws utilized across industries where secure, self-forming connections in sheet materials are required. Key applications include:
- Automotive and Transportation:
Hexagon washer head tapping screws are widely used in automotive assembly and repair, providing high-strength fastening in steel and lightweight metal panels.
- Construction and Engineering:
Recommended for assembling steel frames, cladding, electrical enclosures, and modular components where reliable, vibration-resistant fastening is necessary.
- Appliances and Consumer Goods:
Used in the production of white goods, electronics, and machinery, these screws offer standardized fit and finish for streamlined mass production.
- General Manufacturing:
Suitable for a range of maintenance, installation, and fabrication tasks requiring fast, secure assembly in non-prepared holes.
Related Standards
For comprehensive implementation and quality control, the following related standards are referenced or aligned with SIST EN ISO 7053:2019:
- ISO 1478 - Tapping screws thread
- ISO 2702 - Heat-treated steel tapping screws - Mechanical properties
- ISO 3269 - Fasteners - Acceptance inspection
- ISO 3506-4 - Mechanical properties of corrosion-resistant stainless steel fasteners - Part 4: Tapping screws
- ISO 4042 - Fasteners - Electroplated coating systems
- ISO 4759-1 - Tolerances for fasteners - Part 1: Bolts, screws, studs and nuts - Product grades A, B, C
- ISO 8992 - General fastener requirements
- ISO 10683 - Zinc flake coating systems for fasteners
- ISO 225 - Symbols and descriptions of fastener dimensions
By adhering to SIST EN ISO 7053:2019, manufacturers, suppliers, and designers ensure the use of reliable, standardized hexagon washer head tapping screws that meet international requirements for performance, compatibility, and safety in a wide range of construction, industrial, and engineering applications.
