Overview
IEC 60364-7-716:2023 is an international standard published by the International Electrotechnical Commission (IEC) that specifies requirements for low-voltage electrical installations focused on the distribution of Extra-Low Voltage (ELV) Direct Current (DC) power over Information and Communications Technology (ICT) cable infrastructure. This standard addresses the use of balanced, information technology cables, such as those defined in ISO/IEC 11801-1, for combined telecommunications and ELV DC power distribution.
The document outlines safety, design, erection, and verification requirements for telecommunication infrastructures delivering ELV DC power - including systems such as Power over Ethernet (PoE) defined by IEEE 802.3. It applies to new installations as well as the use of existing telecommunications cabling infrastructure while excluding core and access network equipment such as private branch exchanges (PBX).
Key Topics
-
Scope and Application:
Focuses on low-voltage ELV DC power distribution using balanced ICT cables primarily designed for data transmission, such as Ethernet cabling within specified categories of ISO/IEC 11801-1.
-
Safety and Protection Requirements:
- Protection against electric shock specifically using extra-low voltage (SELV, PELV) systems to ensure user safety.
- Protection against overcurrent and overloads to prevent wiring damage and ensure reliable operation.
- Requirements for coordination between conductors and protective devices to maintain system integrity.
-
Wiring and Equipment Selection:
Detailed guidance on the selection and erection of wiring systems compatible with both telecommunications and ELV power distribution, including permissible cable types, current-carrying capacities, and electrical connections.
-
Standardized Testing and Performance:
References to connector endurance and mechanical operation testing as per IEC 60512-9-3, ensuring reliability and safety of ICT connectors used in power distribution.
-
Normative References:
Incorporates related standards such as IEC 60364 parts 1-6 and 8, IEC 62368-3 for power sourcing equipment, ISO/IEC 11801-1 for generic cabling requirements, and IEC 60364-4-41/4-43 covering protection for electric shock and overcurrent.
Applications
-
Power over Ethernet (PoE) Deployment:
Enables safe and efficient ELV DC power distribution over Ethernet infrastructure commonly used in offices, commercial buildings, and industrial environments.
-
Telecommunications Infrastructure:
Supports dual-use infrastructure where cabling is utilized for both data communication and power supply, optimizing installation costs and spatial requirements.
-
Building and Facilities Management:
Applicable in smart building designs where low-voltage DC power is distributed to devices such as IP cameras, access control systems, wireless access points, and IoT devices.
-
Existing Infrastructure Utilization:
Provides guidelines to safely retrofit existing datacom cable infrastructure for ELV power delivery without compromising telecommunications performance or safety.
Related Standards
-
IEC 60364 Series:
The general framework for low-voltage electrical installations, covering fundamental safety and design principles applicable along with part 7-716 for special installations.
-
ISO/IEC 11801-1:
Defines the generic cabling system for customer premises including balanced cables used for data and power distribution via ICT infrastructure.
-
IEC 62368-3:
Specifies safety requirements for power sourcing equipment used to deliver ELV DC power over ICT cables.
-
IEEE 802.3 (Power over Ethernet):
Industry standard for the delivery of DC power over Ethernet cabling, supported by IEC 60364-7-716 requirements for safe installation and operation.
-
IEC 60364-4-41 and IEC 60364-4-43:
Focus on safety protections against electric shocks and overcurrent conditions, fundamental for ELV DC power distribution infrastructure.
Summary
IEC 60364-7-716:2023 provides critical requirements for integrating ELV DC power delivery with information and communication technology cabling systems. This ensures enhanced safety, reliability, and interoperability for modern electrical installations that combine power and data transmission within low-voltage environments. It is essential for professionals designing, installing, or verifying power distribution over ICT infrastructure to follow this standard to guarantee compliance, performance, and user safety in an evolving technological landscape.
Open preview (PDF)Low-voltage electrical installations - Part 7-716: Requirements for special installations or locations – ELV DC power distribution over information and communications technology (ICT) cable infrastructure
