ISO 2594:1972 PDF
Building drawings — Projection methods
Title (English):
ISO 2594:1972
Building drawings — Projection methods
- Document status:
- Withdrawn
- Format:
- Electronic (PDF)
- Number of pages:
- 4
- Publication date:
- September 1, 1972
- Edition:
- ISO IS 2594 edition 1 version 1
- ICS:
- 01.100.30
Description (English):
Two methods are defined and the symbols specified as shown in the figures. The direct orthogonal projection is symbolized by two parallel arrows running vertically to a dash-and-dot line, and the mirror-inverted orthogonal projection by two parallel double arrows running vertically to a dash-and-dot line.
Technical details
- Technical committee
- ISO/TC 10/SC 8 - Construction documentation
- SKU
- ISO 2594:1972
