Overview
IEC 60749-20:2008 is an international standard developed by the International Electrotechnical Commission (IEC) focusing on semiconductor devices. Specifically, it addresses the mechanical and climatic test methods for assessing the resistance of plastic encapsulated surface mount devices (SMDs) to the combined effects of moisture and soldering heat. This standard is essential for evaluating the durability and reliability of SMDs during manufacturing processes that involve exposure to moisture and high temperatures, such as soldering.
This second edition (2008) updates and replaces the first edition from 2002, incorporating revisions to align with the IPC/JEDEC J-STD-020C classification, referencing IEC 60749-35 for acoustic microscopy, and updating test methods for lead-free solder applications. The test procedures defined are destructive, ensuring rigorous assessment of semiconductor device integrity under combined environmental and mechanical stresses.
Key Topics
- Test Scope and Applicability: Focuses on plastic encapsulated SMDs, providing standardized testing for soldering heat resistance in the presence of moisture.
- Test Apparatus:
- Humidity chambers for moisture exposure.
- Reflow soldering equipment supporting infrared convection, vapour-phase, and wave soldering techniques.
- Specialized holders to position devices during testing.
- Test Procedures:
- Initial visual and electrical inspections, including internal flaw detection using acoustic tomography.
- Moisture soak phases differentiated for dry-packed and non-dry-packed SMDs.
- Soldering heat tests simulating real manufacturing processes with lead-free and SnPb eutectic solder profiles.
- Post-test recovery and final inspection to evaluate damage such as package cracking or electrical failures.
- Classification Profiles: Incorporate temperature profiles relevant to different soldering techniques and materials that influence device reliability.
- Reference Standards: Detailed cross-references to related IEC standards like IEC 60068-2-20 (solderability), IEC 60749-3 (visual inspection), and IEC 60749-35 (acoustic microscopy) to ensure comprehensive testing.
Applications
IEC 60749-20:2008 is widely applied in semiconductor manufacturing, quality assurance, and research & development environments to:
- Qualify plastic encapsulated SMDs before integration into electronic assemblies.
- Ensure compliance with international reliability standards for devices exposed to moisture and thermal stresses during soldering.
- Support transition to lead-free soldering processes, critical for environmental and regulatory compliance (e.g., RoHS).
- Improve product lifetime and reduce failure rates due to soldering-induced defects or moisture-related package cracking.
- Facilitate communication between manufacturers and customers by providing a common test framework accepted globally.
This standard benefits semiconductor manufacturers, contract electronics manufacturers (CEMs), and quality engineers involved in component testing and failure analysis.
Related Standards
- IEC 60068-2-20:2008 – Environmental testing methods related to solderability and resistance to soldering heat for devices with leads.
- IEC 60749-3 – Mechanical and climatic test methods addressing external visual inspection of semiconductor devices.
- IEC 60749-35 – Mechanical and climatic test methods using acoustic microscopy for detecting internal flaws in plastic encapsulated components.
- IPC/JEDEC J-STD-020C – Joint industry standard harmonizing moisture/reflow sensitivity classifications for semiconductor devices.
- RoHS Directive Standards – Compliance with lead-free solder mandates.
Summary
IEC 60749-20:2008 establishes a comprehensive and internationally recognized framework for testing the combined effects of moisture and soldering heat on plastic encapsulated SMDs. By standardizing test apparatus, procedures, and classification profiles, it supports enhanced reliability, quality assurance, and interoperability across semiconductor manufacturing and assembly processes. Incorporating updates for lead-free processes and harmonization with other industry standards, IEC 60749-20 is a key reference for professionals engaged in ensuring the resilience of electronic components in modern electronics manufacturing.
Open preview (PDF)Semiconductor devices - Mechanical and climatic test methods - Part 20: Resistance of plastic encapsulated SMDs to the combined effect of moisture and soldering heat
